CP-34 Organophilic Clay for Paint

CP- 34  is an organo clay (modified bentonite), designed especially for use  in solvent based system. It can be used widely in solvents from low polarity to medium-high polarity.

Properties of CP-34 Organophilic Clay for Paint

Composition                      Organic derivative of a montmorillonite clay

Appearance                       Fine powder, light yellow

Moisture content (105℃,2hr)         ≤3.5%

Loss on ignition (1000℃)            28%-30%

Bulk density                       0.53g/cm3

Fineness (<74μm, %)               ≥98%

Advantages of CP-34 Organophilic Clay for Paint

• High gelling efficiency
• Light color gel
• Produce reproducible thixotropic consistency over a wide temperature range
• Imparts particle suspension, preventing hard settling of pigment and fillers.
• Exerts strong film reinforcing action in organic binder systems.

Application of CP-34 Organophilic Clay for Paint

Bentonite 34  is used in the following applications:

• Marine paint, Industrial paint, heavy-duty, anticorrosion paint such as bituminous coatings, polyester paints, Alkyd paints.
• Sealant
• Inks
• Grease
• Unsaturated polyester putty& Oil Drilling Mud & Coal tar pitch creosite mixture

Using of CP-34 Organophilic Clay for Paint

Bentonite 34  disperses under high shear and requires a polar activator for best efficiency. Heat is not required to obtain good dispersion. Addition levels are typically in 0.2%~2.0%. Polar activator (95% Ethanol or 95% Methanol) is needed. Normally addition level of polar activator is recommended to be 40%~50% of Bentonite 34  in weight. If in xylene system, addition level of polar activator is about 30%-40% of CP-34 in weight.

Pre-gel is made as below procedure.

1. Charge solvent to mill
2. Slowly add Bentonite 34(6-10% by weight of total pregel) to mill under agitation.
3. Mix at high speed for 5 minutes.
4. Add polar activator.
5. Mix at high speed for 5 minutes.

Safety

All safety information is provided in the Material Safety Data Sheets for Zhejiang Camp-Shinning Co.,Ltd..

Package

Kraft bag or kraft complex interior with PE or customized

Storage

Bentonite 34  has a shelf life of 2 years, and should be stored in ventilated cool and dry place.

Notice

The information on use is based on data which are believed reliable, but any recommendation or suggestion made is without guarantee or warranty, since the conditions of use are outside our control. All products are sold on the conditions that purchasers shall make their own tests to determine the suitability of such products for their purpose and that all risks are assumed by user. We disclaim any responsibility for damages resulting from careless or improper handling or use. Nothing herein is to be taken as permission, inducement or recommendation to practice any patented invention without a license.
