CP-EM Organophilic Clay for Synthetic Base Fluids
A high-efficiency rheological additive suitable for synthetic base fluids and all-oil systems, improving carrying capacity and hole cleaning performance. It also serves as an effective suspension agent for polymer slurries.
Composition
Alkyl quaternary ammonium bentonite
Typical Properties of CP-EM Organophilic Clay for Synthetic Base Fluids
The values indicated in this data sheet describe typical properties and do not constitute specification limits.
- Sieve passing (200 mesh/74μm): 90 %
- Specific Gravity: 1.6
- Loss on ignition (1 h, 1000 °C): 46.7 %
- Bulk density: 23 lbf/ft³/368 kg/m³
- Supplied as: Free-flowing powder
Applications of CP-EM Organophilic Clay for Synthetic Base Fluids
Oil-Based Drilling Fluids
Special Features and Benefits
- Minimal shear required
- Dispersible under cold mixing conditions
- Improves sag resistance
- High YP/PV ratio
- Effective in most base oils
- Wet processed, highly refined
- Secondary benefits include: filtration control and emulsion stability
Recommended Uses
CP-EM is recommended for drilling fluids utilizing synthetic fluids as the base oil and in all-oil fluids where temperatures will not exceed 300 °F (150 °C). This product is well suited for mud plants with minimal mixing shear capability.
Example formulation #1: 10.5 pounds/gallon 70/30 Internal Olefin C16-C18
Lab results
